Shelby GT500 rear wing shelf

Shelf inspired by the Shelby GT500 rear wing design, for displaying Hot Wheels die-cast cars collection in a kids' room. Modeled in Fusion.

• You need 2 pieces of each part. Other two parts are mirrored!
• I recommend adding modifiers with denser infill in the slicer to strengthen the mounting points.
• The main body uses 20% infill, while the modifiers use 30% infill, or more.
• You can use some MDF board 600x200 or 800x200mm for shelf itself. (e.g. IKEA BURHULT, TRANHULT… ). Feel free to use any different you want.
• Mounting holes are Ø=5mm (wall) and Ø=4mm (shelf).

Material needed:

• 2 or 4 bigger flathead screws for mounting consoles on the wall - 5x60-80mm
• 4 countersunk screws to mount shelf to the consoles - 4x20mm
• double sided tape for gluing side wings to the shelf
  Tighten the screws gently!

NOTICE: If you have a carbon fiber pattern plate, you’ll get a nice carbon fiber-looking texture on the bottom of your printed parts. Like me :)

Tree (organic) support I used only for mounting holes. Maybe not needed at all.
Printed in PETG, layer 0.16mm, nozzle 0.4mm
